bodor fiber laser tube cutting u10 pro series

Extraordinary performance for extraordinary achievements

Features & Enhancements

Fully automatic operation

The entire system, from transition to processing area, can be completed without any manual intervention. The loading process takes less than 20 seconds, and the unloading mechanism efficiently organizes work pieces based on their varying lengths, eliminating any worries associated with material distribution.

5-axis cutting

The 5-axis linkage (across A, C, X, Y, Z linear axes) processes all sides of an H-beam part in a single setup. The 180° reciprocating motion further guarantees superior surface finishes and overall better part quality.

Compatible drawings with Tekla

With Tekla compatibility, component separation becomes an easy task. Import 3D models created with external formats. For each ungrouped component, the software generates processing codes for operations automatically, enhancing work efficiency.

Locking notch in one operation

To cut structural steel, the laser head maintains a specific distance above the work piece. By executing lock seam/notch cutting in one pass, the equipment eliminates the need for manual polishing and boosts efficiency by 100%.
